Technical Specification

THE B.E.W. RANGE

  • Plastic / PET Granules Ovens : Designed for Plastic / PET Granules used for mineral water bottles, industrial, commercial & house hotel plastic items.
  • Chemical Drying Ovens : Designed for the Chemical, Pharmaceutical, Paint, Pigment, Dyestuff, Foodstuff and other related industries.
  • Bottle Drying Ovens : Designed for Pharmaceutical and Food Stuff Industries
  • Hot Air Sterilising Ovens : Designed for Pharmaceutical and Foodstuff industries.
  • Paint Stoving Ovens : Designed for Steel Furniture and related Utility Products industries.
  • Baking Ovens : Designed for Tin Printing and Electrical Manufacturing industries.

Outstanding Features:

  • Sturdy construction
  • Superior thermal insulation
  • Steady, uniform temperature guaranteed
  • Heaters interlocked with fan
  • Standard sizes available or custom-built to your specifications
  • Excellent after sales service

Technical Details:

Construction:

  • Fabricated from superior M. S. angle irons 2" x 2" x 1/4"
  • Sturdy M.S. / G.I. sheets used inside and outside
  • High grade glass wool, 2" / 3" thick, used between outer and inner sheets to facilitate working temperatures upto 110°C / 200°C
  • Special Silicon based heat resistant aluminium paint coating on inside ; protective red oxide primer and finishing coat of synthetic enamel paint on outside
  • Convenient air inlet and outlet provided
  • Doors on hinges with spring loaded ball and catch type locking arrangement

Heating:

  • Electric or finned electric heaters
  • All electric driers controlled with Digital Temp. Indicator cum Controller
  • Heaters on alternate section to ensure uniform temperature
  • Normal working temperature : 110°C
  • Maximum working temperature : 300°C

Air Circulation:

  • Forced draught, cross flow air circulation to ensure uniform temperature
  • Fans driven by V-belt and pulley arrangement by 3 Ø, 50 N, 440 V AC motors
  • Baffles provided for minimum pressure drop

Trays and Trolleys:

  • Trays 24" x 18" x 2", fabricated from Aluminium, M. S. or Stainless Steel
  • Built in racks available
  • Trolleys fabricated from M. S. sections on 4 wheels, 2-swivel type, for effortless movement (On Request)
  • Trolleys accommodate 24 trays
Model Fan Motor H.P. No. of Motors Heating Load KW Working Size
W D H		 Overall Size
W D H		 App.Cap. Kgs/Batch
BD-06 0.5 1 3 616 x 510 x 686 1118 x 663 x 839 18-20
BD-12 0.5 1 6 616 x 510 x 1296 1118 x 663 x 1448 36-40
BD-24 0.5 1 13.5 947 x 661 x 1296 1448 x 813 x 1448 72-80
BD-48 0.5 2 18.0 1893 x 661 x 1296 2528 x 813 x 1448 145-155
